MORE POWER, MORE PERFORMANCE

All-new air-cooled motor with a nominal power of 4kw with a peak of 8kw. Donning a 33% increase from the original Sting. Notably faster acceleration coupled with a 13% increase in top speed makes the Sting R the industry leader.

MOTOR

Rated Voltage60v (DC)

Rated Power / Peak Power4000W

TransmissionGearbox + Chain

Torque45nm

Peak Efficiency96.6%

Mounting PositionCentre Frame

Cooling MethodAir Cooled

CONTROLLER

TypeFOC

Peak Efficiency92%

BATTERY

Max Range *52 Miles

Battery60v 45Ah

SpeedometerTFT Digital

Charging Time **3 Hours

* Range is dependant on speed/weight/braking and other factors

** Charging time is from 0-100%

CHASSIS

Max Load100kg

Net Weight66kg

ForksManitou (Optional) / Fastace / Talaria Factory

Wheel TypeSpoke Wheels 19x1.6

Dimensions (LxWxH)1880mm x 770mm x 1088mm

Chassis Construction MethodForged 6000 Tons of Pressure

Rear Shock AbsorberTalaria Offroad Performance

Front Tyre Size70/100-19

Rear Tyre Size80/100-19

Chassis SurfaceAnodizing Paint Treated

HeadlightLED

TyresCST

Minimum Ground Clearance260mm
